Product Summary
The BCR401WE6327 is a cost efficient LED driver to drive low power LED’s.
Parametrics
BCR401WE6327 absolute maximum ratings: (1)Supply voltage, VS: 18 V; (2)Output current, Iout: 60 mA; (3)Output voltage, Vout: 16 V; (4)Reverse voltage between all terminals, VR: 0.5V; (5)Total power dissipation, TS ≤ 95℃, Ptot: 500 mW; (6)Junction temperature, Tj: 150℃; (7)Storage temperature, Tstg: -65 to 150℃.
Features
BCR401WE6327 features: (1)LED drive current of 10mA; (2)Output current adjustable up to 60mA with external resistor; (3)Supply voltage up to 18V; (4)Easy paralleling of drivers to increase current; (5)Low voltage overhead of 1.2V; (6)High current accuracy at supply voltage variation; (7)No EMI; (8)Reduced output current at higher temperatures - negative thermal coefficient of -0.3%/K; (9)RoHS compliant (pb-free) small SOT343 package; (10)Qualified according AEC Q101.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BCR401WE6327 |
|
IC LED DRIVER LINEAR SOT-343 |
Data Sheet |
Negotiable |
|
||||||||||||||||||
